●High efficiency, long life and high reliability |
|
●Output protection function: overcurrent/short circuit |
●Ultra-wide operating temperature range -30℃~70℃ |
●Use long-life electrolytic capacitors |
●100% full load aging test |
●Free fan, silent |
●3-year warranty |
name | LPS-15-5 | LPS-15-12 | LPS-15-15 | LPS-15-24 | LPS-15-36 | LPS-15-48 |
Output | DC voltage | 5V | 12V | 15V | 24V | 36V | 48V |
Rated output current | 3A | 1.3A | 1A | 0.625 l A | 0.416A | 0.312A |
Output current range | 0~3A | 0~1.3A | 0~1A | 0~0.625 l A | 0~0.416A | 0~0.312A |
Ripple noise (peak-peak voltage) | 50mV | 120mV | 150mV | 200mV | 200mV | 200mV |
Output voltage regulation range | ±10% of rated output voltage |
Voltage stabilization accuracy | ±2.0% | ±1.0% | ±1.0% | ±1.0% | ±1.0% | ±1.0% |
Power supply voltage regulation rate | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
Load regulation rate | ±1.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
Output start time | <1S (230VAC input), <2S (115VAC input) |
Output hold time | <70ms/230VAC 15ms/115VAC |
enter | Input voltage range | 88Vac~264Vac |
Frequency range | 47Hz~63Hz |
efficiency | 77% | 81% | 81% | 82% | 82% | 82% |
Shock start current (typical) | <30A@230VAC <20A@115VAC Power cooler starts |
Protection function | Overload protection | 105%~135% Rated output current, swaying machine, self-recovery |
Overvoltage protection | 120%~130% Rated output voltage, swaying machine, can be restored by itself |
Short circuit protection | Can be short-circuited for a long time, and can be automatically restored after eliminating the short-circuit |
Working environment | Working temperature and humidity | -20℃~70℃; 25%~90%RH |
Storage temperature and humidity. | -40℃~85℃; 10%~95%RH |
Safety and electromagnetic compatibility standards | Safety standards | Reference GB4943/EN60950, UL62368-1, TUV EN62368-1 |
Insulation strength | Input-output: 3KVac; .Input-ground: 1.5KVac; Output-ground: 0.5KVDC |
other | MTBF (MIL-HDBK-217F) | More than 100,000Hrs (25℃, full load) |
size (Length*width*height) | 62.5*51*28mm |
Package | 130g/PCS |
Cooling method | Natural cooling |
Comments | 1. If not specified, all specification parameters are measured at the rated input, rated load, and 25℃ ambient temperature. |
